Clamps

Isophonic Hanging Clamp

ADVANTAGES: One-piece clamp that facilitates assembly.
APPLICATIONS: PVC and Steel Tubes.Suspended tubes, especially fire protection installations.
TECHNICAL SPECIFICATIONS: Galvanised steel.
EPDM rubber profile.
Sound reduction for DIN 4109: 18db (A).
Temperature resistance: -40º / +110ºC

Clamps M8/10

ADVANTAGES: Side screws with plastic washers.
APPLICATIONS: Horizontal, vertical and suspended installations.
PVC and steel tubes.
TECHNICAL SPECIFICATIONS: Galvanised steel.
Breaking traction load: 6000N.
Maximum safe traction load: 2000N.

Bolts

ADVANTAGES: Simple and fast assembly.
APPLICATIONS: For fastening steel tubes to supports and profiles.
TECHNICAL SPECIFICATIONS: Galvanised Steel.
Bolts DIN 3570.
Bolts  DIN 3570 (Maritime).

Download our catalog Clamps and Bolts
